•Easy to carry with handles
• Specialized Integration Mounting Bracket
• Bluetooth App Connectivity
• Smart Touch Display
• Dynamic Monitoring of SOC
• Durable Mechanical Switches
• 200A Continuous Discharging
• High Temperature Protection
• Overcharge/Discharge Protection
• Over/Short Current Protection
• 10-Years Lifespan
Nominal Voltage: 48 V (51.2 V)
Nominal Capacity: 105 Ah
Stored Energy: 5.12 kWh
Dimension (L×W×H) In Millimeter: 482 × 336 × 254 mm
Weight (kg) No Counterweight: 47.2 kg
| Nominal Voltage | 51.2 V |
| Rated Capacity | 105Ah |
| Absorption Voltage | 56.8 to 57.6 V |
| Float Voltage | 56.0 to 56.8 V |
| Equalize Voltage (if applicable) | 56.8 to 57.6 V (same as absorption) |
| Absorption Time | 30 to 120 minutes |
| Temperature Compensation | No |
| Charge Cut-off Voltage | 58.4 V |
| Discharge Cut-off Voltage | 40 V |
| Recommended Charge Current | 50A |
| Recommended Discharge Current | 50A |
| Maximum Charge Current | 200A |
| Maximum Discharge Current | 200A |
| Bluetooth connection | Yes |
| Self Heating | No |
| IP Standard | IP47 |
| UART | Yes |
| Switch BMS Protection |
Yes High/low voltage Short circuit High/low temperature |
| Cold charging | |
| Internal Resistance | ≤30mΩ |
| BMS Leakage Current | ≤3mA |
| Operating Temperature Charge | 32°F (0°C) to 131°F (55°C) |
| Operating Temperature Discharge | -4°F (-20°C) to 131°F (55°C) |
| Storage Temperature 1 week | -4(-20°C) to 149°F (65°C) |
| Storage Temperature 1 month | -4°F (-20°C) to 113°F(40°C) |
| Storage Temperature 1 year | -4°F (-20°C) to 77°F (25°C) |
| Humidity Operating: | 5% to 90 % RH |
